12.0M~30.0M 请在此填写或选择
(*填写时需要加K/M/G)
8~32pF 请在此填写或选择
| 温度频差VS温度范围 | ±10ppm | ±20ppm | ±30ppm | ±50ppm | ±100ppm |
|---|---|---|---|---|---|
| -10~60℃ | |||||
| -20~70℃ | |||||
| -40~85℃ |
Specs
所选参数Item
KX26Nominal Frequency
左边填写Oscillation Mode
基频/泛音Load Capacitance
左边填写Equivalent Series Resistance
30~60ΩFrequency Tolerance
左边选择Frequency Stability
左边选择Operating Temperature
左边选择Drive Level
100μW max.Shunt Capacitance
5pF maxSpecial Requirement
左边选择Specs
所选参数Item
KX26Nominal Frequency
12.0M~30.0MOscillation Mode
基频/泛音Load Capacitance
8~32pFEquivalent Series Resistance
30~60ΩFrequency Tolerance
±5ppm~±30ppmFrequency Stability
±10ppm~±100ppmOperating Temperature
-55℃ min;+125℃ maxDrive Level
100μW max.Shunt Capacitance
5pF maxSpecial Requirement
有/无
